Brazing 11 gauge steel

I will be brazing a receiver for a derringer kit. Have never done it before. Have access to an oxy/acetylene torch but need advice about which
solder to buy. The ATF won't let the kit vendor give instructions.
A friend of mine says silver solder is the way to go but there are many options. There are the expensive rods that work at low temperatures. http://www.muggyweld.com/?view=ssf6 Only 1,150 deg. ~$80
Or standard solder from Home Depot that is ~$30 for 5 sticks http://www.homedepot.com/webapp/catalog/servlet/Search?storeId 051&langId=-1&catalogId053&keyword=brazing%20rod&Ns=None&Ntpr=1&Ntpc=1&selectedCatgry=Search+All Some of them only require propane, not O/A.
These are the 11 gauge sideplates. http://theflatspot.weebly.com/derringer-45lc410-sideplates--breech-face.html In case you're wondering, this is an old catalog and the prices have gone up significantly.
I downloaded the "Brazing Book" referenced in the instructions. It's 129 pages. Too much information.
Add pictures here
βœ–
<% if( /^image/.test(type) ){ %>
<% } %>
<%-name%>
Add image file
Upload
wrote:

If it were me I would buy some silver solder and flux from a jewelry supply company or a welder's supply company. It will be strongest. There are silver solders which are mostly silver and "silver bearing" solders which are not mostly silver. Stay away from the silver bearing solders, they are not strong enough. You won't need much solder. You will need to read about and practice silver soldering. Check out the book "The Complete Metalsmith" from the library. There is a section in the book about silver soldering. Short and to the point. Remember, you will holding your work in your hand. You don't want it to come apart. Eric
Add pictures here
βœ–
<% if( /^image/.test(type) ){ %>
<% } %>
<%-name%>
Add image file
Upload

Thanks, good advice.
My library has one copy of the book. I placed a hold on it, might get it next week.
I don't want to spend more money on the solder than I do on the other materials, but I do like the idea of using a propane torch instead of O/A.

http://www.youtube.com/watch?v=T2wYgQtPg4g

With one of these. (Amazon.com product link shortened)56922365&sr=8-9&keywordsΎrnzomatic+torch
Was any of the brazing rod on the Home Depot site high enough in silver content? The local welding shop doesn't have a website, maybe I can look there tomorrow.
Add pictures here
βœ–
<% if( /^image/.test(type) ){ %>
<% } %>
<%-name%>
Add image file
Upload
(snip)

(Amazon.com product link shortened) dp/B00008ZA0C/ref=sr_1_9?ie=UTF8&qid56922365&sr=8-9&keywordsbernzomatic+torch
I use a modified BernzOmatic Oxy-propane torch. Only I cut off their O2 regulator for their crappy O2 bottles and used a real regulator with an R sized bottle.
I'm finally breaking down and buying a Smith jewelers torch for my jewelry work.

I don't think Home Despot carries anything with enough silver for you.
Try here: http://www.riogrande.com/Search/silver-solder
You should be able to google the melting points of the easy to hard solders.
Add pictures here
βœ–
<% if( /^image/.test(type) ){ %>
<% } %>
<%-name%>
Add image file
Upload

Thanks for the link. It makes sense to buy by the foot, couldn't see how much shipping runs.
Add pictures here
βœ–
<% if( /^image/.test(type) ){ %>
<% } %>
<%-name%>
Add image file
Upload
wrote:

That torch may work. I don't have any direct experience with it and so can't say.The silver solder at Home Depot probably is low silver content. Since you don't need much solder it won't be too expensive. When you get ready to solder remember, and this is important, that you need to get the work hot fast. Don't pussyfoot around. The flux can only absorb so much oxygen and the longer it takes to heat the part the more oxygen the flux will absorb. When it quits absorbing oxygen the metal starts oxidizing and the solder will not flow. Once this happens your only choice is to let the work cool, clean it back to bright metal, and start over. I like to use firebrick or ceramic blanket to make a little "oven" around the work. This allows the work to be heated much faster. Using regular old brick is dangerous, it may explode when heated. Fire brick is cheap. Get it at a pottery supply or similar. Get the light stuff. Get the cheapest stuff. It cuts easily with a hack saw. Use an old dull blade if you have one. But read that book. You will understand what is going on and have much better chance for success. I learned how to silver solder when I was 14 and I was making precious metal jewelry good enough to sell. So it doesn't take a genius or lots of skill, just follow directions and pay attention. As to strength, Harris Safety Silv 56 is a solder that's usually available at a welders supply and it has a tensile strength of at least 70 ksi. Mild steel is 60 ksi. So it is stronger than mild steel. Other silver solders have even higher strengths. You will probably be better off with the lowest melting temp solder that is at least 70 ksi tensile strength. This is because it is easier to get it hot enough fast enough. And do practice a couple times. A little solder goes a long way because the gap it has to fill is so small. Eric
Add pictures here
βœ–
<% if( /^image/.test(type) ){ %>
<% } %>
<%-name%>
Add image file
Upload

Thanks again. SS 56 lists at 1,200 deg.
I'll practice on similar metals before I waste a $15 part.
I guess I should buy the flux coated, try with propane, and pick up the tanks for O/A just in case.
Add pictures here
βœ–
<% if( /^image/.test(type) ){ %>
<% } %>
<%-name%>
Add image file
Upload
wrote:

It depends on what you are going. If you simply butt two pieces end to end then the approach would be much like torch welding and flux coated or not hardly matters. If there is overlap and you want the silver to penetrate then you probably should use a different approach.
For this technique the flux is mixed with water to make a paste and the parts are painted with flux and then assembled. A spacing of approximately 0.001 - 0.002 is usual for carbon steel. the assembled parts are heated and as they become hotter you will see the flux liquefy - you are nearly there. You want the part to be hot enough to melt the silver. Don't melt it in the torch flame and glob it on, just keep heating and quickly touch the rod to the work from time to time. Eventually you will reach the desired heat and the silver will melt and capillary attraction will suck it into the joint. If you have heated the parts uniformly and evenly you will find that silver applied to one edge will flow completely across a one - two inch joint.
The main problem is heating things evenly. You will need to keep the torch moving and linger a little on the thicker parts to let them heat a bit more than the thinner sections. If you have ever made "sweated" tubing connections then you probably already know the technique.
By the way, assuming sufficient space for the silver to penetrate between the two sides the thinner the gap the stronger the joint.
--
Cheers,

John B.
  Click to see the full signature.
Add pictures here
βœ–
<% if( /^image/.test(type) ){ %>
<% } %>
<%-name%>
Add image file
Upload
On Mon, 04 Feb 2013 16:47:24 -0800, snipped-for-privacy@whidbey.com wrote:

It must be amazing stuff all right. Harris states that Safety-Silv is comprised of 56% Silver, 22% copper, 17% Zinc and 5% Tin. Where did that 70 Ksi come from?
--
Cheers,

John B.
  Click to see the full signature.
Add pictures here
βœ–
<% if( /^image/.test(type) ){ %>
<% } %>
<%-name%>
Add image file
Upload

Look at the strength of 70% copper - 30% zinc brass: http://www.fiskalloy.com/product/c260/
and bronze: http://www.concast.com/c86300.php
Add pictures here
βœ–
<% if( /^image/.test(type) ){ %>
<% } %>
<%-name%>
Add image file
Upload
On Tue, 5 Feb 2013 08:50:59 -0500, "Jim Wilkins"

Silver has an ultimate strength of 24,656 psi Copper    30,457 Tin    29,007 Zinc (wrought)    29,007
--
Cheers,

John B.
  Click to see the full signature.
Add pictures here
βœ–
<% if( /^image/.test(type) ){ %>
<% } %>
<%-name%>
Add image file
Upload
wrote:

Pure iron 4,000 PSI: http://www.steeltalk.com/types_steel.php
What is your point?
Add pictures here
βœ–
<% if( /^image/.test(type) ){ %>
<% } %>
<%-name%>
Add image file
Upload
wrote:

I should have said that generic 56% silver solders have a yield of over 60 ksi and ultimate yield of 70 ksi. I used the Harris name because it is available widely. And it's true, silver solders, AKA silver brazing alloys, are amazingly strong when used properly. Eric
Add pictures here
βœ–
<% if( /^image/.test(type) ){ %>
<% } %>
<%-name%>
Add image file
Upload
On Tue, 05 Feb 2013 08:59:41 -0800, snipped-for-privacy@whidbey.com wrote:

I think that you are getting the ultimate strength of the silver solder mixed up with the strength of the joint that can be made with it, which is far, far, greater then the strength of the silver solder alone.
--
Cheers,

John B.
  Click to see the full signature.
Add pictures here
βœ–
<% if( /^image/.test(type) ){ %>
<% } %>
<%-name%>
Add image file
Upload
On 06/02/13 10:54, John B. wrote:

Nope. Try a google.
If you look here: http://www.jm-metaljoining.com/pdfs/Silver%2520Brazing%2520Alloys%2520and%2520Fluxes.pdf
you will find Johnson Matthey's publicity blurb for their brazes and silver solders. On p 11 you will find that that their 56% silver solders have a tensile strength of 410 n/mm^2, or 60,000 psi.
There is also a 44% alloy with a tensile strength of 545 N/mm^2, or 80,000 psi. It's a bit harder to use though.
Or here, where the UTS of a 56% silver solder is given as 71,000 psi: www.muggyweld.com/?view=ssf6
56% silver solder is strong stuff. UTS varies between about 50 ksi for cheap stuff to 70 ksi plus for the good stuff. Yield strengths of 60 ksi are not uncommon for premier brands.
Ans yes, joint strengths can be higher, up to maybe 120 ksi.
-- Peter Fairbrother
Add pictures here
βœ–
<% if( /^image/.test(type) ){ %>
<% } %>
<%-name%>
Add image file
Upload
I finally was able to get the pdf mentioned below.
http://www.jm-metaljoining.com/pdfs/Silver%20Brazing%20Alloys%20and%20Fluxes.pdf
The %2520 is a double space concept but only singles work out. Might be due to a foreign font used.
Martin
On 2/6/2013 5:45 AM, Peter Fairbrother wrote:

http://www.jm-metaljoining.com/pdfs/Silver%2520Brazing%2520Alloys%2520and%2520Fluxes.pdf

Add pictures here
βœ–
<% if( /^image/.test(type) ){ %>
<% } %>
<%-name%>
Add image file
Upload
On 07/02/13 05:13, Martin Eastburn wrote:

http://www.jm-metaljoining.com/pdfs/Silver%20Brazing%20Alloys%20and%20Fluxes.pdf

I dunno, works fine for me.
But try:
https://www.kimballmidwest.com/Catalog/CatalogIndex.aspx?p=5.6.628.358.3855
76,000 psi Tensile 60,000 psi Yield
or just google something like "silver 56% tensile" and look for the manufacturer's hits. It shouldn't take long to convince you that 70 ksi UTS, 60 ksi yield is fairly typical for a good 56% silver brazing alloy.
Lots of people find it surprising, but it's so.
-- Peter Fairbrother
Add pictures here
βœ–
<% if( /^image/.test(type) ){ %>
<% } %>
<%-name%>
Add image file
Upload
wrote:

No I'm not. I was commenting on the strength of the solder itself independent of joint design. Joint design can indeed lead to an even stronger assembly than the tensile strength of the solder itself would suggest. Bad joint design can lead to a weaker assembly too. Eric
Add pictures here
βœ–
<% if( /^image/.test(type) ){ %>
<% } %>
<%-name%>
Add image file
Upload

I already own the propane torch and I'll try it first. Went to Home Depot this morning and was disappointed they only had Lincoln Electric KH515 brazing rod which has no silver at all.
I assume that the Lincoln Electric Stay-Silv 56 is the same as Harris Safety-Silv 56, but they don't stock it at my local store. I can't get to the welding shop today. 70,000 PSI sounds plenty strong.
The Depot did have a MAP gas rig for only $42. http://www.homedepot.com/p/t/202185045/5yc1v?catalogId 053&langId=-1&keyword=map+torch&storeId051&N%ecodZ5yc1v&R 2185045#.URE8cfLYGSo It is supposed to get significantly hotter than propane, and I would be willing to purchase one for this project - could probably find uses for it in the future.
Add pictures here
βœ–
<% if( /^image/.test(type) ){ %>
<% } %>
<%-name%>
Add image file
Upload
wrote:

If by "propane" you mean a torch that connects to a cooking gas bottle it will melt the solder but they need a bloody great flame to do it. If it is MAPP gas, I think it is sold as Benzomatic in America, then it will likely do everything you want to do with it. They don't sell it over here but I acquired a couple of bottles and the torch from somewhere and built two bicycle frames with it.... just ran out last week, now I'll have to buy an oxy-cooking gas rig :-(

I wouldn't assume, check the specs. I once bought some "silver solder" - got a fabulous buy on it too - only to discover that it is intended for copper tubing and didn't work reliably on steel.

As I said above I used MAPP gas to build two bicycle frames.
--
Cheers,

John B.
  Click to see the full signature.
